After having setup a Sitecom 300N wireless range extender (WL-330 v1 002) it suddenly stopped working after months of usage.
- Sitecom Wifi Range Extender N300 Manual Software
- Manuale D'uso Sitecom Wifi Range Extender N300
- Sitecom Wifi Range Extender N300 Manual Instructions
Get the most out of your WLX-2006v1001 Wi-Fi Range Extender N300. Find FAQs, firmware, manuals and installation videos for your Sitecom product.
Even after powering the device off and back on again, and after re-applying its settings, the wireless repeater doesn't want to repeat the wireless signal again.
How to fix this?
- Need a manual for your Sitecom WL-330 Range Extender? Below you can view. A range extender amplifies an existing wireless signal. This was helpful (62).
- You find the best setup location for optimal Wi-Fi coverage. 7 PC NETWORK ADAPTER SETUP. The WLX-2006 Wall Mount Range Extender N300.
Sitecom Wifi Range Extender N300 Manual Software
Pro BackupPro Backup1 Answer
1. Factory reset
First factory reset the WL-330 device.
Go to the WL-330 web admin interface, tab 'Toolbox' -> tab 'Back-up' -> label 'Restore to Factory default' choose the [ Reset ] button.
In case you can't access the web admin interface, you can also press the 'Reset' button (on the rear panel of the device) and hold for 10 seconds to restore all settings to factory defaults.
Manuale D'uso Sitecom Wifi Range Extender N300
2. Site Survey
Secondly re-issue a site survey. Go to tab 'Basic Settings' -> label 'Site Survey:' -> button [ Site Survey ] and select your Wi-Fi SSID, finally choose button [ Done ].
3. Channel number
At the 'Basic Settings' screen, verify that the Wi-Fi channel number is identical to the one, chosen in the Site Survey.
4. Apply basic settings
Now apply the basic settings, and at the 'Save settings successfully!' screen choose button [ Continue ] to set the password before restarting the device.
5. Set Wi-Fi security
Next go to 'Advanced Settings' -> 'Security'. In most cases the 'Encryption' drop down menu can be changed to 'WPA Pre-Shared Key'.
When you are not sure which value to choose and your are working on a Mac, connect to the wireless network you wish to repeat, then press the Alt-key while clicking on the Wi-Fi icon () in the menu bar. This will show detailed settings like PHY mode, BSSID, Channel number, Security, etcetera.
6. Set Wi-Fi password
Next fill out your Wi-Fi password near the 'Pre-Shared Key' label and press [ Apply ]. In the following 'Save settings successfully!' screen you now choose for [ Apply ] again to store all your settings and restart the Wi-Fi repeater configured with your new settings.
7. Disable DHCP server (optional)
In case you also want to bridge on the wired ethernet interface, in other words when connecting your computer via a cable to the WL-330 and wish to have an IP address from the same IP range as when connecting directly to the wireless network, then you need to disable the DHCP server that is built in to the WL-330. Go to tab 'Toolbox' -> label 'DHCP Server :' -> drop down menu 'Enabled' and change that to 'Disabled', [ Apply ] and [ Apply ].
